The SPRO ANPR cameras will allow you to identify and record number plates, ideal for car parks and driveways. Number plates can be added to black/white lists that can control a barrier. With the DHANPRIPQ40/0832R there is an option to install the unit without an NVR and to record onto a micro SD card.

The maximum speed in which the DHANPRIPQ40/0832R can read and record number plates is 74mph (120 km/h) and can be installed between 8 to 30 meters away from the target area.

Specifications:
Model Number	DHANPRIPQ40/0832R
Image Sensor	1/1.8" CMOS
Image Resolution	2688 x 1520
Electronic Shutter Speed	Auto / Manual 1/25 s-1/100,000s
Max. Detection Speed	120km/h / 74mph
Max. Illumination	0.001 Lux@F1.6 (Colour, 30 IRE) 0.0002 Lux@F1.6 (B/W, 30 IRE) 0 Lux (Illuminator on)
RAM	4Gb
ROM	1Gb
S/N Ratio	>56dB
Scanning System	Progressive scanning
Lens
Focal Length	8 mm–32 mm
Field of View	H: 39.9° (W)—15.1° (T) V: 21.8° (W)—8.5° (T) D: 46.6° (W)—17.4° (T)
Focus Control	Auto, area focus, manual
Number of Lens	1
Lens Type	Motorised Vari-focal
Max. Aperture	1.6
Iris Control	P-Iris
DORI Distance	W: Detect: 160.0 m (524.93 ft) Observe: 64.0 m (209.97 ft) Recognise: 32.0 m (104.99 ft) Identify: 16.0 m (52.49 ft) T: Detect: 406.9 m (1334.97 ft) Observe: 162.8 m (534.12 ft) Recognise: 81.4 m (267.06 ft) Identify: 40.7 m (133.53 ft)
Illuminator
Illuminator Number	4
Illuminator On/Off Control	Auto, Manual
Illuminator Type	Dual Illuminators (730 nm IR/warm light)
Illuminator Distance	ANPR: 30 m (98.43 ft) Video monitoring: 60 m (196.85 ft)
Smart Illumination	According to the brightness of the environment, the camera automatically adjusts the intensity of its light to reveal the details of moving targets. Devices with warm light can automatically adjust the light intensity according to the time.
Infrared Wavelength	730 nm
Video
Video Resolution	Main stream: 4M (2688 × 1520)/1080p (1920 × 1080)/720p (1280 × 720) Sub stream: 720p (1280 × 720)/960H (960 × 576, 960 × 480) /D1 (704 × 576, 704 × 480)/CIF (352 × 288, 352 × 240)
Stream	PAL: Main stream (2688 × 1520@25 fps, 1920 × 1080@25 fps, 1280 × 720@25 fps), sub stream (1280 × 720@25 fps, 960 × 576@25 fps, 704 × 576@25 fps, 352 × 288@25 fps); NTSC: Main stream (2688 × 1520@30 fps, 1920 × 1080@30 fps, 1280 × 720@30 fps), sub stream (1280 × 720@30 fps, 960 × 480@30 fps, 704 × 408@30 fps, 352 × 240@30 fps)
Video Compression	H.264H; H.264B; H.264M by default; H.265; MJPEG; H.264M
Video Bit Rate	H.264M: 2,179 kbps–13,074 kbps H.264H: 2,179 kbps–13,074 kbps H.265: 2,179 kbps–13,074 kbps MJPEG: 6,537 kbps–39,223 kbps
Scene Self-adaptation (SSA)	Yes
Gain Control	Manual; Auto
Noise Reduction	3D NR
Region of Interest (RoI)	Yes, 3
Image Tampering Prevention	Yes. Watermarks can be added to video and images. The watermark can also be verified.
Bit Rate Control	CBR; VBR
Function
Storage	Built-in TF card port. Supports Kingston 16 G, 32 G, 128 G, 256 G
Restricted List / Trusted List	Allow list: 110,000 Blocklist: 110,000
IVS	Intrusion detection, loitering detection, up to 4 areas can be set.
Basic Event	Alarms for events of defocus, no storage card error, network disconnection, IP conflict, and illegal access.
Sound and Light Alarm	Yes, blue & red indicator, and supports broadcasting custom audio.
Alarm Linkage	Upload to FTP/Memory card, notify monitoring centre, send e-mail, trigger alert output, snapshot and active deterrence.
Capture Distance	8 m–30 m (26.25 ft–98.43 ft)
Detected Width	6 m–8 m (19.69 ft–26.25 ft)
Network
Network Protocol	HTTP; Https; 802.1x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; NTP; SFTP;DDNS; SNMP; PPPoE
API	Yes
SDK	Yes
Interoperability	ONVIF (Profile S/Profile T); CGI; ITSAPI; P2P
Management Software	DMSS
Security	Username and password; MAC address; HTTPS; IEEE 802.1x; network access control
Browser	IE; Chrome; Firefox
Image Encoding Format	JPEG
Image Setting	Brightness; contrast; saturation; gamma; sharpness; gain; white balance
Day / Night	IR filter, support three modes: Colour ; B/W; auto
WDR	140 dB
HLC	Yes
BLC	Yes
White Balance	Auto; Regional Custom; Manual; Outdoor; Natural; Street Lamp
Digital Detail Enhancement	Yes
OSD Overlay	Supports overlay of time; address (position of channel), lane (number/direction), plate (number and colour), vehicle (speed, colour, type)
Audio
Audio Port	Yes
Built-in MIC	Yes; Pick-up distance: 3m (9.84ft), Sampling Rate:48k
Built-in Speaker	Yes; Power:2W
Port
Audio Output	1 channel (RCA port)
Network Port	RJ-45 (10/100/1000 self-adaptive Ethernet Port)
Alarm Input	2, optocoupler input (wet node on-off value: 5 V)
Alarm Output	2, relay output (2A 30 VDC/0.5A 125 VAC), which can be connected to devices such as barriers
RS-485	2 (half duplex, Transparent, DHRS, Push Data through Serial Port)
Reset Button	Yes
Wiegand	1 channel, SHA-1 26 bit
Performance
Max. Number of Passed Vehicles	10,000
Max. Number of Connections	10
Intelligence
AI Recognition	Recognised vehicle types, vehicle signs, vehicle colour, vehicle plate, vehicle without plate.
Video Metadata	Displays the intelligent frame, plate and vehicle paths.
Vehicle Brand	Recognises 147 vehicle logos.
Vehicle Type Recognition	Recognises 10 vehicle types: Large bus, heavy Truck, medium truck, sedan, van, light truck, medium bus, SUV, MPV, Pickup
Vehicle Colour	Recognises 12 vehicle colours: Grey, black, white, silver, blue, green, purple, red, orange, pink, brown and yellow.
Country and Region Supported by ANPR	Baseline support: GCC (U.A.E., Saudi Arabia, Morocco, Oman, Iraq, Egypt, Jordan, Qatar, Kuwait, Bahrain, Lebanon) Europe (Netherlands, France, Germany, Britain, Italy, Poland, Belgium, Bulgaria, Serbia, Slovakia, Spain, Denmark, Turkey, Israel, Czech Republic, Bosnia and Herzegovina, Switzerland, Austria, Hungary, Romania, Lithuania, Latvia, Sweden, Estonia, Portugal, Greece, Slovenia, Luxembourg, Palestine, Lebanon, Ireland, Finland, Norway, Croatia, North Macedonia) Russian-speaking regions (Russia, Ukraine, Kyrgyzstan, Uzbekistan, Moldova, Lithuania, Latvia, Georgia, Azerbaijan, Turkmenistan) SADC (Uruguay, Paraguay, Brazil, Argentina, Chile, Colombia, Peru, Ecuador, Guyana) North America (United States, Canada) Can be customized: Mongolia, Japan, Philippines, Vietnam, Laos, Cambodia, Myanmar, Thailand, Malaysia, Singapore, Indonesia, Bangladesh, India, Pakistan, Curacao, Mexico, Guatemala, Costa Rica, Australia, New Zealand, Tunisia, Algeria, Ethiopia, Tanzania, Uganda, Equatorial Guinea, Nigeria, Zambia, Mozambique, South Africa, Mauritius
Capture Rate	In the recommended installation and lighting condition, the vehicle capture rate ≥ 99%
Recognition Rate	In the recommended installation and lighting condition, the recognition rate for positive and departing vehicles ≥ 96%; the recognition rate for European vehicle plates ≥ 98%
Performance
Remote Control	Yes
Communication Band	433MHz; 868 MHz
Remote Control Distance	15m (49.21 ft) (In an open, undisturbed environment)
Power Supply	12 VDC, 2 A and POE:802.3at,Type 2,Class 4,(44V to 57V), 0.455A to 0.351A,max.20W
Power Consumption	Power consumption in different conditions: No lighting < 6 W Lighting <12 W Speaker and Red/Blue Light Warning on < 17 W
Protection	IK10; IP67
Material	Aluminum alloy body + Plastic
Product Dimensions	395.0 mm × 120.8 mm × 127.8 mm (15.55" × 4.76" × 5.03") (L × W × H)
Net Weight	2.3 kg (5.07 lb)
Gross Weight	3.2 kg (7.05 lb)
Storage Humidity	–40 °C to +70 °C (–40 °F to +158 °F)
Storage Temperature	≤ 95% (non-condensing)
Operating Temperature	–30 °C to +65 °C (–22 °F to +149 °F)
Operating Humidity	10%–90% (non-condensing)
Certifications	CE-EMC; CE-LVD; CE-RED; FCC

Through our logistic partners we are able to deliver to most areas in the UK on a next business day service.
Our standard cut off time on the website for standard next day delivery is 4pm but you will still be able to call our sales team anytime up to 4:30pm to place an order.
We also offer a premium next day pre 12pm and pre 10:30am service to these areas as well as a Saturday and Saturday pre 10:30am delivery. For areas outside of here, such as the Highlands, Isle of Man and Channel islands we are able to provide a 2 business day service.

For orders outside of the UK please call 0121 663 6151 to speak to a member of the team who will be able to assist you.

Part Number	DHANPRIPQ40/0832R
Brand	SPRO
Colour	Grey
Housing Style	Bullet
Camera Resolution	4 Megapixel
Lens Type	Motorised
Lens Size	8 - 32 mm
ColourNight	No
Illumination Type	IR
White Light Distance	N/A
IR Light Distance	up to 30m
Ingress Protection	IP67
Built-in Mic	Yes
Built In Speaker	Yes
SD Card Slot	256GB
Starlight	No
WDR	120dB
RCA Audio Jack	1 In
Alarm Tracking	No
Active Deterrence	No
SMD	No
Perimeter Protection	No
Tripwire	No
Intrusion	No
Face Detection	No
Face Recognition	No
ANPR	Yes
Meta Data	No
Flame Detection	No
People Counting	No
AcuPick	No
Heat map	No
