Signal strength detection.
Low battery alarm.
Temperature measurement.
Frequency hopping function and two-way communication technology ensure communication stability.
Cloud update and automatic recovery from update failure.
| Specifications: | |
|---|---|
| Model Number | DA-ARD323-W2-868S |
| Port | |
| Indicator Light | 1 x green alarm indicator |
| Button | 1 x power button |
| Function | |
| Tamper Alarm | Yes |
| Remote Upgrade | Cloud Update |
| Test Mode | Yes |
| Low Battery Alarm | Yes |
| Search | Signal Strength Detection |
| Wireless | |
| Carrier Frequency | 868.0 MHz–868.6 MHz |
| Communication Distance | Up to 1,200 m (3,937.01 ft) in an open space |
| Communication Mechanism | Two-way |
| Frequency Hopping | Yes |
| Encryption Mode | AES128 |
| General | |
| Power Supply | CR123A battery |
| Power Consumption | Max. 125 mW |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
| Operating Humidity | 10%–90% (RH). |
| Product Dimensions | 100.2mm × 20.8mm × 20.3mm (3.94”× 0.82” ×0.80”) (L × W × H) |
| Packaging Dimensions | 135.0 mm × 98.5 mm × 27.8mm (5.31" × 3.88" × 1.09") (L × W × H) |
| Installation | Bracket mount |
| Net Weight | 70 g (0.15 lb) |
| Gross Weight | 115 g (0.25 lb) |
| Certifications | CE |
| Battery Life | 4 years (The external input type is NO) 2 years (The external input type is NC or Pulse) |
| Casing | PC + ABS |
| Temperature | |
| Measuring Range | –15 °C to +65 °C (+5 °F to +149 °F) (indoor) |
| Measuring Precision | ± 1 °C (± 1.8 °F) |
| Resolution | 1 °C (33.8 °F) |
| Specification | |
| Sensor | Reed Switch |
| Scenario | Non-metal doors |
| Movement Distance | < 40 mm (1.57") |
| Peripherals | |
| External Zone | 1-channel dry contact input |
Through our logistic partners we are able to deliver to most areas in the UK on a next business day service.
Our standard cut off time on the website for standard next day delivery is 4pm but you will still be able to call our sales team anytime up to 4:30pm to place an order.
We also offer a premium next day pre 12pm and pre 10:30am service to these areas as well as a Saturday and Saturday pre 10:30am delivery. For areas outside of here, such as the Highlands, Isle of Man and Channel islands we are able to provide a 2 business day service.
For orders outside of the UK please call 0121 663 6151 to speak to a member of the team who will be able to assist you.
| Part Number | DA-ARD323-W2-868S |
| Brand | Dahua |
| Colour | White |
| Range | Dahua AirShield |
