Connects up to 32 peripherals.
Two-way RF communication.
LED indicator displays device status.
Supports manual and auto paring, extending RF distance for your security system.
Auto switches from dual antennas to reduce blind areas.
Cloud update and auto recovery of update failure.
Battery backs device working for over 35 hours when external power supply fails.
| Specifications: | |
|---|---|
| Model Number | DA-ARA43-W2-868 |
| Input/Output | |
| Wireless Zone | 32 x wireless peripherals |
| Port | |
| Storage Battery | Built-in lithium battery |
| Indicator Light | 1 that indicates pairing and working |
| Power Switch | 1 x power switch |
| Function | |
| Remote Upgrade | Cloud Update |
| Low Battery Alarm | Yes |
| Search | Signal Strength Detection |
| Tamper Alarm | Yes |
| Power Failure Protection for Configured Parameters | Yes |
| Disconnection Detection of External Power Supply | Yes |
| Pairing Mode | Auto/Manual |
| Wireless | |
| Carrier Frequency | 868.0 MHz–868.6 MHz |
| Communication Distance | Up to 1,600 m (5249.34 ft) in an open space |
| Communication Mechanism | Two-way |
| Frequency Hopping | Yes |
| Encryption Mode | AES128 |
| General | |
| Power Supply | 12 VDC, 1.5 A |
| Battery Life | Battery standby time: 35h |
| Operating Environment | –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
| Operating Humidity | 10%–90% (RH). |
| Product Dimensions | 163.0 mm × 163.0 mm × 32.0 mm (6.42" × 6.42" × 1.26") |
| Packaging Dimensions | 219.0 mm × 187.0 mm × 91.0 mm (8.62" × 7.36" × 3.58") |
| Installation | Wall mount; Desktop |
| Net Weight | 0.32 kg (0.71 lb) |
| Gross Weight | 0.74 kg (1.63 lb) |
| Certifications | CE |
| Battery Life | 3 years |
| Casing | PC + ABS |
Through our logistic partners we are able to deliver to most areas in the UK on a next business day service.
Our standard cut off time on the website for standard next day delivery is 4pm but you will still be able to call our sales team anytime up to 4:30pm to place an order.
We also offer a premium next day pre 12pm and pre 10:30am service to these areas as well as a Saturday and Saturday pre 10:30am delivery. For areas outside of here, such as the Highlands, Isle of Man and Channel islands we are able to provide a 2 business day service.
For orders outside of the UK please call 0121 663 6151 to speak to a member of the team who will be able to assist you.
| Part Number | DA-ARA43-W2-868 |
| Brand | Dahua |
| Colour | White |
| Range | Dahua AirShield |
