Ajax IndoorCam

Wi-Fi AI-powered indoor security camera with motion detection, two-way audio, and encrypted video streaming. Designed for indoor monitoring and integration with Ajax security systems.

Camera

Image sensor: 4 MP CMOS
Maximum resolution: up to 2688 × 1520 px

Field of view:

• Horizontal: 110°

• Vertical: 60°

Night illumination:

• Smart IR illumination up to 8 m

• Automatic brightness adjustment to avoid overexposure

Video

Video protocol: JetSparrow (encrypted peer-to-peer streaming)
Video codec: H.264
Dynamic range: HDR for improved visibility in bright and dark areas

Storage

• Ajax Cloud (coming soon)

• Ajax NVR support

Audio

Microphone: built-in for audio recording
Speaker: built-in for two-way communication
Audio codec: G.722
Audio processing: noise suppression and echo cancellation

Intelligent detection

• Motion detection (PIR sensor + software analysis)

• AI object detection:

  • People

  • Pets

  • Vehicles

Motion sensor

Sensor: 1 × PIR
Detection distance: up to 4 m
Detection angle:

• Horizontal: 110°

• Vertical: 60°
  Sensitivity: 3 adjustable levels

Connectivity

Wi-Fi: 802.11 b/g/n
Frequency: 2.4 GHz
Video bitrate: up to 2 Mbit/s

Backup communication:

• Jeweller

• Wings

These proprietary Ajax wireless technologies transmit alarms, commands, events, and photo verifications when connected to a hub.

Key features

• Two-way voice communication

• Visual verification of Ajax alarms

• LED status indicator

Protection

• Holding screw for secure mounting

• Encrypted mTLS connection

• Ajax Cloud authentication

• Secure Boot

• Verified OTA firmware updates

Installation

• Designed for indoor use only

• Avoid installation in direct sunlight to prevent overheating

Power supply

Power input: 12 V DC ±20%, 1 A
Power consumption: TBC

Enclosure

Dimensions: 128 × 74 × 76 mm
Weight: 235 g
Operating temperature: 0 °C to +40 °C
Humidity: up to 90% (non-condensing)
Protection class: IP20

Color:

• Black (RAL 9005)

• White (RAL 9003)
